Daver Steels Bar & Cable Systems manufacture the Daver Tie Rod system and the Daver Compression Strut system. Both systems are high strength structural components with a high specification finish for constructional and architectural applications.
Please note that Daver Steels (Bar & Cable systems) Ltd are no longer a subsidiary of Daver Steels Ltd. The Bar & Cable Systems part of the company was sold off in 2016 and has relocated to a separate site in Goldthrope, South Yorkshire, under the management of Beta Engineering Services Ltd.
The DST520 structural tie rod system is produced in carbon steel and stainless steel with a characteristic yield strength of 520 N/mm2 and are CE approved to Execution Class 4 (EXC4) BS EN 1090-1:2009 + A1:2011.
The system offers a standard range of fork end tie rods, complete with pins, lock covers and turnbuckles enabling them to offer tension rod assemblies from:
M12 to M100 in carbon steel
M12 to M56 in stainless steel.
DST520 tendons are pre-assembled in the factory and set to their nominal pin-to-pin length for immediate incorporation into the structure.
Daver Compression Strut System
Daver Steels (Bar & Cable) manufacture a range of adjustable compression struts in carbon steel and stainless steel. Both systems are supplied with CE certification up to Execution Class 3 (EXC3) BS EN 1090-1:2009 + A1:2011.
The compression strut comprises of a central tubular section with threaded fork-end and pin connection at each end & are pre-assembled in the factory and set to their nominal pin-to-pin length for immediate incorporation into the structure.
The Daver Compression Strut system is available in:
Carbon steel from M12 to M100
Stainless steel system from M12 to M56.
The Daver Steels DST520 system provides a technical solution to your tie rod requirements. The sales team have a wide range of experience with tie rod systems and can aid architects, designers, structural steel fabricators and end users.
For further information on the Daver Steels tie rods, compression struts or high tensile threaded bars please visit: https://www.daverbarandcable.co.uk
